Shakeproof

BosScrew™
•	Won't Loosen
•	No Additional Hardware
•	Removable and Re-Usable
•	Higher Assembly Strip Torques
•	No Complicated Calculations

Hi-Lo®
•	Double lead high and low thread
•	High thread at 30º included angle

Hi-Lo Plus ®
•	High and low threads incorporate the 30º included angle with a 45º angle step on the trailing flank.

Plastite 60-1®
•	The 60º penetrates deeply into the work piece, without stripping, resisting pullout forces.

Plastite 48-2®
•	Twin lead, sharper (48º) threads.
•	Cracking of plastic reduced.

SinuLOC™
•	The calculated combination of pressure and location ensures that there is added performance with no damage to the threads.

Tap/R®
•	Re-usability in the same hole without cross threading
•	Reduces drive torque while increasing strip torque
•	Rapidly locates pilot holes due to unthreaded relief areas
•	Removes paint and porcelain from pilot holes

TapTite® & TapTite II ®
•	Reduces friction during driving to assure low driving torque.
•	Generates a prevailing torque that exceeds the level of a locking screw.

Thread Cutting Screws
•	A shank slot in the body of the screw threads provides true cutting action, eliminating a separate tapping operation and generating a perfectly mated thread that is reusable.

Cyclone® Self-drilling Screws
•	The Cyclone screw's serrated helical shoulder actually bites into sheet metal, enabling the screw to absorb higher tightening torque, which adds to increased backout resistance.

Fasteners
•	Machine Screws
•	Custom Multi-Die Cold Headed Parts

GX® Self-extruding Screws
•	With its eccentric thread section, this screw extrudes thin sheet metal upward and downward, significantly increasing both the thread engagement area and torque absorbtion capability.

Sems®& Square Cone® Sems
•	Eliminates multiple part hand assemblies and dropped parts
•	Reduces part numbers and inventories
•	Increases assembly efficiency and therefore productivity

TEKS®

TEKS form close mating threads and produce a complete fastening system in a single operation.

Stems®

Designed for plastic-to-metal assembly applications, the preassembled washer has a unique standoff column that bears against the metal tapping plate, protecting the bearing surface of any soft or resiliant mating material.

Helical Lock Washers
•	Spring (Split) Lock
•	The split in the lock washer absorbs initial driving torque and visually closes under nominal bolt loading.

Tooth Lock Washers
•	The teeth work to maintain fastening tension
•	Reacts instantly to any loosening force
•	Absorbs shock and vibration

Wave/Spring Washers
•	Provide a compensating spring force.
•	Sustain a load or absorb shock.
•	Load and deflection are the key performance characteristics.

Shaft and Bearing Retainers
•	Designed to hold securely on unthreaded metal or plastic shafts, rods or studs.
•	Securely holds the bearing, leaving it free to rotate.

Bolt Retainers (Push-on)
•	Used to retain screws or bolts in place prior to the final assembly of a female thread (nut).

image here

Bearing Retainers
•	Securely holds the bearing, leaving it free to rotate.

Spring Nuts
•	Flat nuts, J-nuts, U-nuts. Wide range panel nuts, U-clips and specials.
•	One-piece, self locking, multi-purpose mechanical fasteners that prevent screws from loosening due to vibration.

Precision Custom Springs
•	Single & Double Torsional
•	Compression Springs
•	Extension Springs
•	Spiral Springs
•	Battery Springs
•	Made to your print

Custom Wire Forms
•	Custom Designed Linkage
•	Hooks and Brackets
•	Custom Engineered or Made to Print Speciality Items
